Options Available: Internal Disconnect • Upgradeable Diagnostics: Surge Event Counter, Beeper, & StatusRelay (1 Form C Contacts) • NEMA 4X Enclosure • Low Impedance Micro-Z cable (Click here)

Options Available: Internal Disconnect • Upgradeable Diagnostics: Surge Event Counter, Beeper, & Status
Relay (1 Form C Contacts) • NEMA 4X Enclosure • Low Impedance Micro-Z cable (Click here)

Features:

  • 120LS: I peak=120,000A/Phase (8x20μs waveform)

  • UL1449 5th Edition

  • NEMA LS1-1992

  • Three times redundant protection paths per phase

  • Employs new 40kA varistors with built in high-speed thermal disconnect

  • Solid copper bus bar construction

  • Field-replaceable modules

  • EMI/RFI noise filtering

  • Continuously monitored protection circuits

  • Internal and external status indicators

  • NEMA 4 enclosure

20 Year No-Nonsense Warranty.
Lifetime on Replaceable Modules.
